Researchers have developed a new method for manufacturing infrared sensors using environmentally friendly quantum dots, sidestepping the reliance on toxic heavy metals that has limited the widespread use of night vision and other heat-sensing technologies. The breakthrough promises a cheaper, safer, and more scalable way to produce the core components of systems that allow us to see in the dark, with significant implications for autonomous vehicles, medical imaging, and security applications.
The growing demand for sophisticated infrared imaging has been hampered by a significant roadblock: the best-performing sensors have traditionally been built with materials containing lead and mercury. These substances are heavily restricted by environmental regulations, creating a conflict for manufacturers between performance and compliance. This regulatory pressure has created a bottleneck, slowing the adoption of infrared technology in civilian and consumer electronics just as the need for it is exploding. The new process, developed by a team at New York University’s Tandon School of Engineering, uses colloidal quantum dots made from silver selenide, offering a high-performance and eco-friendly alternative.
Overcoming Industry Bottlenecks
For years, the infrared imaging industry has faced a dilemma. The push for advancements in self-driving cars, security systems, and non-invasive medical diagnostics has driven up the demand for high-fidelity infrared detectors. However, environmental safety standards have simultaneously tightened, phasing out the use of hazardous materials common in electronics. This has put companies in a difficult position, forcing a choice between using restricted heavy metals for superior performance or settling for less effective, compliant alternatives.
Furthermore, traditional manufacturing methods for infrared detectors are both costly and slow. The process involves meticulously placing atoms one by one to build up the pixels of a sensor, a method akin to assembling a complex puzzle under a microscope. This painstaking fabrication is difficult to scale, keeping production costs high and limiting the technology’s availability for widespread commercial applications. The new quantum dot approach addresses both the environmental and production challenges simultaneously.
A Solution Based in ‘Quantum Ink’
The NYU researchers’ solution is centered on colloidal quantum dots, which are semiconductor nanocrystals so small that their properties are governed by quantum mechanics. Instead of being constructed atom-by-atom on a rigid substrate, these quantum dots are synthesized entirely in a liquid solution, creating a product that behaves like an ink. This “quantum ink” can then be applied using scalable coating techniques, similar to the roll-to-roll printing processes used for newspapers or product packaging.
The Shift to Silver Selenide
The team specifically focused on photodetectors made from silver selenide (Ag2Se). This compound was known to be a potentially effective and more environmentally compliant material for infrared sensing, but it had been difficult to work with. Previous attempts to manufacture silver selenide sensors were often plagued by problems like electrochemical instability and the formation of cracks or voids in the material, which degraded performance. The researchers needed to find a new way to process the material into a smooth, uniform, and reliable film.
Innovations in Manufacturing and Performance
The key to overcoming the challenges of silver selenide was a technique called solution-phase ligand exchange (SPLE). This process modifies the surface chemistry of the quantum dots, making the resulting “ink” more conductive and allowing it to be deposited in a single, smooth step. The SPLE method produces uniform, crack-free coatings that are ideal for scalable manufacturing, solving the primary issues that had held back the material’s use.
The resulting devices set new performance benchmarks for systems based on silver selenide. The sensors demonstrate remarkable sensitivity and speed, capable of detecting light signals as faint as a single nanowatt and responding on a microsecond timescale—hundreds of times faster than the blink of a human eye. In technical trials, the photodetectors achieved reproducible responsivities as high as 150 milliamperes per watt, confirming the viability of the manufacturing process and the quality of the resulting sensor.
Building a Complete Imaging System
A functional infrared detector requires more than just the light-sensing material. A critical secondary component is a transparent electrode capable of efficiently collecting the electrical signals generated by the quantum dots when they are struck by infrared light. This component must be conductive enough to transmit the signal but also transparent enough to not block the incoming light.
This latest work on eco-friendly quantum dots builds upon the same research team’s earlier success in developing new transparent electrodes from silver nanowires. These nanowire-based electrodes are highly effective at collecting electrical signals while remaining almost entirely transparent to infrared light. By combining the environmentally compliant silver selenide quantum dots for sensing with the high-performance silver nanowire electrodes for signal collection, the researchers have developed a comprehensive solution that addresses the two major components of an infrared imaging system.
The Future of Short-Wave Infrared
This breakthrough has the potential to dramatically expand the use of short-wave infrared (SWIR) imaging, a technology distinct from the more familiar thermal imaging. While thermal cameras detect emitted heat, SWIR sensors detect reflected light in the non-visible infrared spectrum. This allows SWIR cameras to capture images with high resolution, contrast, and shadows, much like a standard black-and-white photograph, but with the ability to see through atmospheric conditions like smoke, fog, and haze.
By providing a pathway to lower-cost, scalable, and non-toxic SWIR sensors, this research opens the door to a host of new applications. Industries from agriculture to quality control could use it to detect moisture content or identify bruising on produce. In manufacturing, SWIR cameras can see through materials like silicon, allowing for real-time inspection of semiconductor wafers. Ultimately, this technology could become common in consumer-level devices, enhancing the capabilities of everything from home security systems to the advanced sensors that guide autonomous vehicles.
